Working initial visualization of a static decision tree.

manim_ml/decision_tree/decision_tree.py

@@ -5,27 +5,263 @@
 from manim import *
 from manim_ml.one_to_one_sync import OneToOneSync

+import numpy as np
+from PIL import Image

-class LeafNode(VGroup):
-    pass
+def compute_node_depths(tree):
+    """Computes the depths of nodes for level order traversal"""
+    def depth(node_index, current_node_index=0):
+        """Compute the height of a node"""
+        if current_node_index == node_index:
+            return 0
+        elif tree.children_left[current_node_index] == tree.children_right[current_node_index]:
+            return -1
+        else:
+            # Compute the height of each subtree
+            l_depth = depth(node_index, tree.children_left[current_node_index])
+            r_depth = depth(node_index, tree.children_right[current_node_index])
+            # The index is only in one of them
+            if l_depth != -1:
+                return l_depth + 1
+            elif r_depth != -1:
+                return r_depth + 1
+            else:
+                return -1

+    node_depths = [depth(index) for index in range(tree.node_count)]

-class NonLeafNode(VGroup):
-    pass
+    return node_depths

+def compute_level_order_traversal(tree):
+    """Computes level order traversal of a sklearn tree"""
+    def depth(node_index, current_node_index=0):
+        """Compute the height of a node"""
+        if current_node_index == node_index:
+            return 0
+        elif tree.children_left[current_node_index] == tree.children_right[current_node_index]:
+            return -1
+        else:
+            # Compute the height of each subtree
+            l_depth = depth(node_index, tree.children_left[current_node_index])
+            r_depth = depth(node_index, tree.children_right[current_node_index])
+            # The index is only in one of them
+            if l_depth != -1:
+                return l_depth + 1
+            elif r_depth != -1:
+                return r_depth + 1
+            else:
+                return -1

-class DecisionTreeDiagram(Graph):
-    """Decision Tree Digram Class for Manim"""
+    node_depths = [(index, depth(index)) for index in range(tree.node_count)]
+    node_depths = sorted(node_depths, key=lambda x: x[1])
+    sorted_inds = [node_depth[0] for node_depth in node_depths]

-    pass
+    return sorted_inds

+def compute_node_to_parent_mapping(tree):
+    """Returns a hashmap mapping node indices to their parent indices"""
+    node_to_parent = {0: -1} # Root has no parent
+    num_nodes = tree.node_count
+    for node_index in range(num_nodes):
+        # Explore left children
+        left_child_node_index = tree.children_left[node_index]
+        if left_child_node_index != -1:
+            node_to_parent[left_child_node_index] = node_index
+        # Explore right children
+        right_child_node_index = tree.children_right[node_index]
+        if right_child_node_index != -1:
+            node_to_parent[right_child_node_index] = node_index
+
+    return node_to_parent
+
+class LeafNode(Group):
+    """Leaf node in tree"""
+
+    def __init__(self, class_index, display_type="image", class_image_paths=[],
+            class_colors=[]):
+        super().__init__()
+        self.display_type = display_type
+        self.class_image_paths = class_image_paths
+        self.class_colors = class_colors
+        assert self.display_type in ["image", "text"]
+        if self.display_type == "image":
+            self._construct_image_node(class_index)
+        else:
+            raise NotImplementedError()
+
+    def _construct_image_node(self, class_index):
+        """Make an image node"""
+        # Get image
+        image_path = self.class_image_paths[class_index]
+        pil_image = Image.open(image_path)
+        node = ImageMobject(pil_image)
+        node.scale(1.5)
+        rectangle = Rectangle(
+            width=node.width + 0.05,
+            height=node.height + 0.05,
+            color=self.class_colors[class_index],
+            stroke_width=6
+        )
+        rectangle.move_to(node.get_center())
+        rectangle.shift([-0.02, 0.02, 0])
+        self.add(rectangle)
+        self.add(node)
+
+class SplitNode(VGroup):
+    """Node for splitting decision in tree"""
+
+    def __init__(self, feature, threshold):
+        super().__init__()
+        node_text = f"{feature}\n<=  {threshold:.2f} cm"
+        # Draw decision text
+        decision_text = Text(
+            node_text,
+            color=WHITE
+        )
+        # Draw the surrounding box
+        bounding_box = SurroundingRectangle(
+            decision_text,
+            buff=0.3,
+            color=WHITE
+        )
+        self.add(bounding_box)
+        self.add(decision_text)
+
+class DecisionTreeDiagram(Group):
+    """Decision Tree Diagram Class for Manim"""
+
+    def __init__(self, sklearn_tree, feature_names=None,
+                class_names=None, class_images_paths=None,
+                class_colors=[RED, GREEN, BLUE]):
+        super().__init__()
+        self.tree = sklearn_tree
+        self.feature_names = feature_names
+        self.class_names = class_names
+        self.class_image_paths = class_images_paths
+        self.class_colors = class_colors
+        # Make graph container for the tree
+        tree, _, _ = self._make_tree()
+        self.add(tree)
+
+    def _make_node(
+        self,
+        node_index,
+    ):
+        """Make node"""
+        is_split_node = self.tree.children_left[node_index] != self.tree.children_right[node_index]
+        if is_split_node:
+            node_feature = self.tree.feature[node_index]
+            node_threshold = self.tree.threshold[node_index]
+            node = SplitNode(
+                self.feature_names[node_feature],
+                node_threshold
+            )
+        else:
+            # Get the most abundant class for the given leaf node
+            # Make the leaf node object
+            tree_class_index = np.argmax(self.tree.value[node_index])
+            node = LeafNode(
+                class_index=tree_class_index,
+                class_colors=self.class_colors,
+                class_image_paths=self.class_image_paths
+            )
+        return node
+
+    def _make_connection(self, top, bottom, is_leaf=False):
+        """Make a connection from top to bottom"""
+        top_node_bottom_location = top.get_center()
+        top_node_bottom_location[1] -= top.height / 2
+        bottom_node_top_location = bottom.get_center()
+        bottom_node_top_location[1] += bottom.height / 2
+
+        line = Line(
+            top_node_bottom_location,
+            bottom_node_top_location,
+            color=WHITE
+        )
+
+        return line
+
+    def _make_tree(self):
+        """Construct the tree diagram"""
+        tree_group = Group()
+        max_depth = self.tree.max_depth
+        # Make the root node
+        nodes_map = {}
+        root_node = self._make_node(
+            node_index=0,
+        )
+        nodes_map[0] = root_node
+        tree_group.add(root_node)
+        # Save some information
+        node_height = root_node.height
+        node_width = root_node.width
+        scale_factor = 1.0
+        edge_map = {}
+        # tree height
+        tree_height = scale_factor * node_height * max_depth
+        tree_width = scale_factor * 2 ** max_depth * node_width
+        # traverse tree
+        def recurse(node_index, depth, direction, parent_object, parent_node):
+            # make the node object
+            is_leaf = self.tree.children_left[node_index] == self.tree.children_right[node_index]
+            node_object = self._make_node(node_index=node_index)
+            nodes_map[node_index] = node_object
+            node_height = node_object.height
+            # set the node position
+            direction_factor = -1 if direction == "left" else 1
+            shift_right_amount = 0.9 * direction_factor * scale_factor * tree_width / (2 ** depth) / 2
+            if is_leaf:
+                shift_down_amount = -1.0 * scale_factor * node_height
+            else:
+                shift_down_amount = -1.8 * scale_factor * node_height
+            node_object \
+                .match_x(parent_object) \
+                .match_y(parent_object) \
+                .shift([shift_right_amount, shift_down_amount, 0])
+            tree_group.add(node_object)
+            # make a connection
+            connection = self._make_connection(parent_object, node_object, is_leaf=is_leaf)
+            edge_name = str(parent_node)+","+str(node_index)
+            edge_map[edge_name] = connection
+            tree_group.add(connection)
+            # recurse
+            if not is_leaf:
+                recurse(self.tree.children_left[node_index], depth + 1, "left", node_object, node_index)
+                recurse(self.tree.children_right[node_index], depth + 1, "right", node_object, node_index)
+
+        recurse(self.tree.children_left[0], 1, "left", root_node, 0)
+        recurse(self.tree.children_right[0], 1, "right", root_node, 0)
+
+        tree_group.scale(0.35)
+        return tree_group, nodes_map, edge_map
+
+    def create_level_order_expansion_decision_tree(self, tree):
+        """Expands the decision tree in level order"""
+        animations = []
+        # Get sklearn nodes in the correct order
+        node_level_order = compute_level_order_traversal(tree)
+        # Add the node to the graph object
+        # Position the node
+        # Expand the graph in the given order.
+
+        return AnimationGroup(
+            *animations,
+        )
+
+    @override_animation(Create)
+    def create_decision_tree(self, traversal_order="level"):
+        """Makes a create animation for the decision tree"""
+        if traversal_order == "level":
+            return self.create_level_order_expansion_decision_tree(self.sklearn_tree)
+        else:
+            raise Exception(f"Uncrecognized traversal: {traversal_order}")

 class DecisionTreeEmbedding:
     """Embedding for the decision tree"""

     pass

-
 class DecisionTreeContainer(OneToOneSync):
     """Connects the DecisionTreeDiagram to the DecisionTreeEmbedding"""


manim_ml/neural_network/neural_network.py

@@ -170,7 +170,8 @@ class NeuralNetwork(Group):
                 after_layer_args = {}
                 if layer.input_layer in layer_args:
                     before_layer_args = layer_args[layer.input_layer]
-                current_layer_args = layer_args[layer]
+                if layer in layer_args:
+                    current_layer_args = layer_args[layer]
                 if layer.output_layer in layer_args:
                     after_layer_args = layer_args[layer.output_layer]
                 # Merge the two dicts

tests/test_decision_tree.py

@@ -0,0 +1,49 @@
+from manim import *
+from manim_ml.decision_tree.decision_tree import DecisionTreeDiagram
+from sklearn.tree import DecisionTreeClassifier
+from sklearn import datasets
+import sklearn
+import matplotlib.pyplot as plt
+
+def learn_iris_decision_tree(iris):
+    decision_tree = DecisionTreeClassifier(
+        random_state=1,
+        max_depth=3,
+        max_leaf_nodes=6
+    )
+    decision_tree = decision_tree.fit(iris.data[:, :2], iris.target)
+    # output the decisioin tree in some format
+    return decision_tree
+
+def make_sklearn_tree(dataset, max_tree_depth=3):
+    tree = learn_iris_decision_tree(dataset)
+    feature_names = dataset.feature_names[0:2]
+    return tree, tree.tree_
+
+class DecisionTreeScene(Scene):
+
+    def construct(self):
+        """Makes a decision tree object"""
+        iris_dataset = datasets.load_iris()
+        clf, sklearn_tree = make_sklearn_tree(iris_dataset)
+        # sklearn.tree.plot_tree(clf, node_ids=True)
+        # plt.show()
+
+        decision_tree = DecisionTreeDiagram(
+            sklearn_tree,
+            class_images_paths=[
+                "images/iris_dataset/SetosaFlower.jpeg",
+                "images/iris_dataset/VeriscolorFlower.jpeg",
+                "images/iris_dataset/VirginicaFlower.jpeg",
+            ],
+            class_names=[
+                "Setosa",
+                "Veriscolor",
+                "Virginica"
+            ],
+            feature_names=["Sepal Length", "Sepal Width"]
+        )
+        # create_decision_tree = Create(decision_tree)
+        self.add(decision_tree)
+        decision_tree.move_to(ORIGIN)
+        # self.play(create_decision_tree)
